Features & Specifications:
IGBT based heavy duty inverter DC power source for Submerged Arc Welding,Carbon Air Arc Gouging (CAAG) and Electro Slag Welding With unique high-power non-parallel inverter technology, the machine has simplified structure and reduced the potential failure points, avoided the different current issue among the modules caused by parallel method. Digital inverter control, high accuracy, more stable ARC output. Digital MCU intelligent control, fault self- diagnosis, output fault code. Energy saving, economic and environment-friendly, efficiency up to 89%. With power supply voltage fluctuation compensation function, 20% voltage fluctuation is allowed. The power factor can reach 0.94, which has little influence on the power grid. Has multi protection function, such as overheat, over current, over voltage, under voltage, phase missing etc. CC/CV DC output optional.
FEATURES
Oscillating tip, left-mid-right three position welding position, oscillating assembly is stable and reliable.
Chromium Zirconium Copper contact tip, alloy copper material torch soft connection with good conductive, those can increase life span.
Torch body is made of stainless steel and plasma paint technology,
Automatic flux feeding and recovery and sensors to sense sidewall variations.
Key Features
The POWER IND 250C is a semi-automatic, constant voltage (CV) DC welding power source. This machine features a smaller footprint and the same rugged look that customers have come to expect from all Lincoln Electric industrial welding power sources.
Advantage
Light weight and portable- easy to move and suitable for stacking
Features Lincoln’s latest generation Inverter technology for maximum reliability
Thermal overload protection available for stable welding output under all demanding conditions
Machine comes with inbuilt 2 roll drive wire feeder with quick changeover wire feeding mechanism
Built in wire feeder
Equipped with a user friendly control panel which includes optional features such as 4step/2step switch and 0.8/1.0 mm wire selection switch.
Suitable for welding in all positions, and on a broad range of applications and materials such as carbon steel and stainless steel. The machine is especially well suited for general purpose shop floor and automotive sector requirements
Key Features
The POWER IND 400I is a semi-automatic, constant voltage (CV)/ constant current (CC) DC welding power source. This machine features a smaller footprint and the same rugged look that customers have come to expect from all Lincoln Electric industrial welding powersources.
Advantage
Light weight and portable- easy to move and suitable for stacking
Features Lincoln’s latest generation Inverter technology for maximum reliability
Thermal overload and single phasing protection for stable welding output under all demanding conditions
Light weight 4 roll drive wire feeder with servo control motor and quick changeover wire feeding mechanism
Adjustable inductance control - Gives operator control over spatter issues
Adjustable crater voltage and crater current control – Gives operator control to achieve good weld ends.
Enclosed wire feeder with spool cover to avoid rusting of wire
Wire diameter range- Solid wire :- 0.8 -1.2 mm Flux cored:- 1.2 – 1.6mm
High output, reliable industrial machine The Speedtec® range is the solution for Industrial Multi-process applications. With modular and compact design this welding set is easy to move around site. Transport is trouble free thanks to the lower weight of this new design. With the latest high frequency inverter technology, the arc is precisely controlled, many times faster than conventional analogue power sources. The electrical characteristics of the welding power can be changed by software in real time updates. A wide range of synergic programs are available as standard allowing simple yet precise control of welding parameters for the best results every time. The Speedtec® machines utilise the very latest power source technology for efficiency and lower energy consumption. Their advanced Inverter technology will save both time as well as energy. Driven by Lincoln Electric’s Green Initiative, we aim to reduce the costs to you as well as the environment. Thesewelding sets are available as 400A rated at 80% or 500A rated at 50% duty cycle (at 40°C). With the PF-46 wire feed unit the welding set can support the MIG processes with synergic programs for Steel, Stainless Steel, Aluminium and Flux cored wires. Lift TIG and Stick functions are available as standard.
Features
• Pulsed MIG process-great for low spatter, low heat input and out-of-position applications-makes virtually any operator a better welder!
• Premium welding behaviour on CV MIG & Stick welding.
• Variable inductance control.
• Synergic capability.
• Job control with limits secured by a password (PF-46).
• Continuous control of wire feed speed and voltage.
• Remote control on the gun (PF-46 & optional for PF-44).
• Pre-setting (PF-41 excl.) & Multi procedure (PF-46).
Whether in a shop or in the field, the Flextec 350X welder is built to perform. Equipped with CrossLinc® technology, the Flextec 350X welder can be controlled from hundreds of feet away without expensive and inconvenient control cables. Desert Duty® and IP23 rated, it can withstand harsh outdoor conditions and outperform other welders in its class. In the field, the Flextec 350X Construction is a welder's most effective weapon. As a rugged multi-process power source, this model stays reliable and offers much more than other inverter-based welders in its class. In the shop, the Flextec 350X Standard model is built to work with all 42V feeders for your factory applications. It is also compatible with Arclink® digital feeders to provide synergic modes and memories for quick setup and seamless connectivity. The Flextec 350X PowerConnect model adds the ability to weld with any input voltage between 200 and 600 volts and adds basic pulsed MIG output as a standard feature.
Portable, Powerful, Multi-Process. The multi-process Power Wave® S350 is packed with Lincoln Electric performance technology on both the input and output side. It provides an extremely fast arc response, includes over 65 standard welding waveforms for optimized performance on almost any application and efficiently converts input power to reduce operational costs – all in a compact, rugged case
FEATURES PowerConnect® Technology (Patent-Pending) – Automatically adjusts to input power from 200-600V, 50 or 60 Hz, single phase or three phase. Welding output remains constant through the entire input voltage range. Tribrid® Power Module – Exceptional welding performance with high power factor and efficiency. CheckPoint® – A cloud-based system to view or analyze your welding data. Track equipment usage, store weld data, configure fault limits and more. Optional 115V (10A) AC Duplex Auxiliary Power Receptacle – Features patentpending Surge Blocker™ Technology to ensure simultaneous welding performance is not compromised by high starting current devices such as grinders (typically requiring 60A or more peak surge current). Compact and Durable Case – IP23 rated to withstand harsh environments. Standard Ethernet – Allows for effortless software upgrades through powerwavesoftware.com
